Observe
Capture load measurements, disturbance history, installation constraints, and the operational consequence of losing each circuit.
Turn a scattered equipment list into a documented panelboard design basis. The service path connects measured demand, electrical compatibility, coordination objectives, protection planning, and alarm ownership so procurement can compare complete configurations rather than isolated model names.
Structured technical scope
Consolidate device wattage, startup behavior, power-factor constraints, operating criticality, and forecast growth into one load basis. The output separates essential loads from convenience loads and identifies assumptions that still require measurement.
Compare ride-through, orderly shutdown, generator-start bridging, and service-continuity targets at actual load. Coordination remains tied to the selected model, enclosure condition, ambient temperature, and expansion configuration.
Review nominal voltage, frequency, plug and receptacle, upstream branch protection, grounding, available fault current context, and output connection method before equipment release.
Define local display, trip monitoring, dry-contact, or remote metering needs. Assign alarm destinations and escalation paths for overcurrent, overload, bypass, communication loss, and breaker replacement events.
Record breaker family references, access requirements, inspection cadence, configuration records, protection settings considerations, and end-of-life decision points for maintainers.
Capture load measurements, disturbance history, installation constraints, and the operational consequence of losing each circuit.
Test capacity and coordination cases using load current, supported topology, battery arrangement, and controlled growth margin.
Cross-check connectors, ratings, management interfaces, approvals, ventilation, access, and upstream-downstream coordination.
Issue a reviewable basis with assumptions, selected options, open decisions, and the maintenance data future technicians need.
A panelboard can appear adequate on headline capacity while missing the required output connection, waveform, shutdown path, breaker access, or communications option. A documented process exposes those gaps before they become commissioning delays. It also provides a clear record when loads change, breakers age, or responsibility transfers between IT, facilities, contractors, and service teams.
Send the present load, expected additions, input supply, coordination target, mounting limits, and alarm requirements for a structured review.
Request a Sizing Session
